Ubiquiti UniFi USW-Ultra-60W — Compact 8-Port PoE Switch

The Ubiquiti UniFi Switch Ultra 60W (USW-Ultra-60W) is a compact, fan-free Layer 2 switch featuring 8 Gigabit Ethernet ports—7 PoE+ outputs and 1 PoE++ input. Designed for versatile deployment (desktop, wall, or magnetic), it offers a flexible power budget up to 52W PoE+ via its included 60W adapter. It’s ideal for powering cameras, VoIP phones, and access points in tight space

  • Data Sheet
Request a Quote
9 people are viewing this product

Description

The USW-Ultra-60W combines flexibility, performance, and space-saving design in one. Equipped with seven 30W PoE+ output ports and a PoE++ input port for powering the unit itself, it supports multiple power options including PoE++, PoE+, or AC adapter—providing up to 52W total PoE budget.

Despite its compact size, it delivers full Layer 2 performance—16 Gbps switching capacity, 8 Gbps non-blocking throughput, and 12 Mpps forwarding rate. It supports VLANs, storm control, port isolation, jumbo frames, and more, all manageable via the UniFi Network Controller.

Encased in a durable polycarbonate shell and weighing just 320 g, the USW-Ultra-60W is perfect for discreet installation in networks where aesthetics and form factor matter.

Official Documents

  • Datasheet & Tech Specs via Ubiquiti’s Ultra 60W tech specs page.

  • Installation Guide & Marketing Imagery available via the same source.

Application

Compact PoE hubs for cameras, VoIP phones, or Wi-Fi APs; Small offices, retail, hospitality, or point-of-entry deployments where space-saving is essential.

Key Features

  • 8 GbE ports: 7 × PoE+ out (30 W each) + 1 × PoE++ in

  • Flexible power options: PoE++ (42 W), PoE+ (16 W), 60W adapter (52 W), 210W adapter (202 W peak)

  • Switch fabric: 16 Gbps capacity, 8 Gbps throughput, 12 Mpps forwarding

  • Rich Layer 2 features: VLAN, STP/RSTP, port mirroring, jumbo frames, storm control, etc.

  • Fanless + Mountable options: desktop, wall, or magnetic

  • Durable polycarbonate housing, lightweight design

  • Manager via UniFi Network Controller

  • NDAA, CE, FCC, IC, and Anatel certified

Specifications

Specification Details
Brand Ubiquiti
Model / Code UniFi Switch Ultra 60W (USW-Ultra-60W)
Ports 7 × GbE PoE+ out, 1 × GbE PoE++ in
Switching Capacity 16 Gbps
Non-Blocking Throughput 8 Gbps
Forwarding Rate 12 Mpps
Power Options PoE++ input (42 W); PoE+ input (16 W); 60 W AC input (52 W); 210 W AC input (202 W)
Max PoE per Port 30 W
Power Consumption 9 W (PoE input), 8 W (adapter)
Dimensions 203 × 76 × 33 mm (8 × 3 × 1.3″)
Weight Device: 320 g; Mounts: 45 g; Adapter: 330 g
Enclosure Polycarbonate
Layer 2 Features VLAN, storm control, port mirroring, jumbo frames, egress/broadcast limits
Certifications NDAA compliant; CE, FCC, IC, Anatel
Operating Temp PoE++ input: –30 to 60 °C; 60W adapter: –20 to 45 °C; 210W adapter: –20 to 60 °C
Humidity 10–90% non-condensing
