MikroTik ATL 5G R16

The MikroTik ATL 5G R16 is an outdoor 5G modem/router built for remote, rural, or failover scenarios. It features a 16 dBi directional antenna, 4×4 MIMO, built-in eSIM + microSIM support, and a Gigabit Ethernet port with PoE-in. Powered by a dual-core ARM CPU with 512 MB RAM, it supports RouterOS v7. Rugged and weatherproof (IP66), it’s designed for demanding outdoor installations.

Description

The MikroTik ATL 5G R16 is MikroTik’s first outdoor 5G device that integrates a high-gain antenna with a cutting-edge Release 16 5G modem and embedded eSIM capabilities. It is tailored for deployments where cellular connectivity is the primary WAN—such as rural areas, IoT sites, remote links, or as a failover link in enterprise networks.

It includes a 16 dBi directional antenna and supports 4×4 MIMO across key low and middle frequency bands, including Band 28, to ensure robust coverage even in challenging areas. The device accepts PoE-in (802.3af/at, 12–56 V) power, enabling a single-cable installation for data and power.

On the inside, it runs on a dual-core ARM 88F3720 CPU (800 MHz) with 512 MB RAM and 32 MB Flash storage, under RouterOS v7 (License level 3). Connectivity is through a 1 GbE RJ45 port. For SIM support it offers microSIM + eSIM, with built-in support for MikroTik’s own connectivity plans.

The ATL’s enclosure is IP66-rated, and the form factor is designed to shed snow and water. It is rated to operate between –40 °C and +70 °C. Typical power consumption is 10 W (with or without attachments).

This device is ideal when you want a rugged, self-contained 5G WAN endpoint with minimal additional antenna infrastructure. It works effectively as a primary link or backup, especially in locations where fiber isn’t viable.

Applications

Outdoor WAN / cellular backhaul, rural & remote connectivity, failover links for critical infrastructure, IoT cellular gateways, MDU / remote branch connectivity.
Its directional antenna and environmental ruggedness make it suitable for challenging installations with minimal infrastructure overhead.

Key Features

✔️ Integrated 16 dBi directional antenna with 4×4 MIMO for extended range
✔️ Supports eSIM + microSIM for flexible SIM provisioning
✔️ Gigabit Ethernet + PoE-in enables a single-cable solution
✔️ Release 16 5G modem with LTE fallback (Cat 20)
✔️ Rugged IP66 enclosure, passive cooling, wide temp range
✔️ Compact design shed snow and water, ideal for outdoor mounting
✔️ Runs RouterOS v7 (License level 3) with full management capabilities
✔️ Typical power consumption ~10 W

Specifications

SpecificationDetails
BrandMikroTik
Model / Product CodeATL 5G R16 (ATLGM&RG520F-EU)
CPU / ChipsetDual-Core 88F3720, 800 MHz
Memory512 MB RAM
Storage32 MB Flash
Wi-Fi StandardNot applicable
Wireless Capabilities5G / LTE modem (no Wi-Fi client)
Ethernet Ports1 × 1 GbE RJ45
PoE InYes — 802.3af/at, 12–56 V input
PoE OutNot supported
USBNot supported
Mobile / Modem5G (Release 16, NSA/SA), LTE Category 20, 4×4 MIMO
Supported BandsMany FDD / TDD LTE and 5G bands including Band 1,3,5,7,8,20,28,38,40,41,42,43,75,76,77,78 etc.
Power / ConsumptionMax 10 W, typical 10 W (no attachments)
CoolingPassive (no fans)
Operating Temperature–40 °C to +70 °C
Environmental RatingIP66
Mounting OptionsOutdoor pole / wall mounting
Dimensions311 × 311 × 179 mm
Certifications & ApprovalsCE, RoHS (others not explicitly listed)
Warranty1 year
Package ContentsATL 5G R16 Main Unit, Power adapter, PoE injector, mounting kit
