Description

The USW-EnterpriseXG-24 sets a new standard in multigigabit network architecture with 24 copper 10 GbE ports for high-speed edge device connections and dual 25 GbE SFP28 ports for ultra-fast uplink capacity. Boasting a 580 Gbps switching capacity and 290 Gbps non-blocking throughput, it delivers 432 Mpps forwarding rate and smooth performance in demanding scenarios.

The switch is equipped with a 1.3″ LCM color touchscreen for real-time diagnostics and supports SmartPower RPS redundancy (optional), enhancing reliability. With a compact 1U rack design, SGCC steel chassis, and robust ESD protection, it’s ready for deployment in enterprise-grade installations.

Application

Core or aggregation switch in enterprise or campus networks, high-bandwidth uplinks for servers, storage, or inter-switch backhaul, professional PoE environments needing high speed

Key Features

• 24 × 10 GbE RJ45 ports and 2 × 25 GbE SFP28 uplinks

• 580 Gbps switching capacity; 290 Gbps non-blocking throughput; 432 Mpps forwarding rate

• Layer 3 capabilities: static routing, inter-VLAN routing, DHCP server/relay

• 1.3″ touchscreen (LCM) for diagnostics and status

• Supports USP-RPS for power redundancy

• ESD protection: ± 16 kV (air), ± 12 kV (contact)

• Durable SGCC steel chassis; rack-depth optimized (442 × 285 × 44 mm)

• Managed via UniFi Network Controller and mobile app

• NDAA, CE, FCC, IC, and Anatel compliant
