Ubiquiti UniFi U6-Mesh — Wi-Fi 6 AP

The Ubiquiti UniFi U6-Mesh is a versatile Wi-Fi 6 access point designed for indoor and outdoor wireless coverage. Supporting dual-band 2.4 GHz and 5 GHz with 6 spatial streams, it delivers strong performance and reliable connectivity for homes, small businesses, and ISP networks. With Gigabit Ethernet and 802.3af PoE compatibility, the U6-Mesh is easy to deploy on walls, poles, or ceilings. Its sleek, weather-resistant design ensures durability, making it a smart and flexible choice for expanding network coverage.

Get a Quote
5 people are viewing this product

Description

The Ubiquiti UniFi U6-Mesh is a high-performance Wi-Fi 6 access point that provides fast and reliable wireless connectivity in a compact and weather-resistant form factor. Designed for both indoor and outdoor environments, it supports the latest 802.11ax standard and operates simultaneously on 2.4 GHz and 5 GHz bands. With six spatial streams, it can efficiently handle multiple devices, ensuring smooth browsing, streaming, and business operations.

Equipped with a Gigabit Ethernet port and supporting 802.3af PoE, the U6-Mesh is simple to power and integrate into UniFi network deployments. Its flexible mounting options — including wall, pole, and ceiling — allow seamless installation in a variety of scenarios. The device is weatherproof when installed with its LED facing upward, making it ideal for outdoor mesh setups.

Powered and managed via the UniFi Network application, administrators gain centralized visibility, configuration, and monitoring for optimal performance. Whether extending Wi-Fi in enterprise offices, retail spaces, hospitality venues, or outdoor public areas, the U6-Mesh ensures reliable coverage and robust connectivity with the efficiency of Wi-Fi 6 technology.

Application

Home Wi-Fi, Small offices, Enterprise networks, ISPs

Key Features

✔️ Wi-Fi 6 (802.11ax) with dual-band 2.4 GHz & 5 GHz
✔️ 6 spatial streams for high-capacity performance
✔️ Gigabit Ethernet port with 802.3af PoE support
✔️ Indoor and outdoor operation with weather-resistant design
✔️ Flexible mounting options: wall, pole, or ceiling
✔️ Managed via UniFi Network application
✔️ Sleek, compact housing for unobtrusive deployments
✔️ Ideal for mesh networking and coverage extension

Specifications

SpecificationDetails
BrandUbiquiti
Model / Product CodeUniFi U6-Mesh
DimensionsØ48.5 × 159.5 mm (Ø1.9 × 6.3″)
Weight400 g (14.1 oz)
Wi-Fi Standard802.11ax (Wi-Fi 6)
Wireless Capabilities2.4 GHz: 2×2 MU-MIMO, up to 573.5 Mbps (BW40) 5 GHz: 4×4 MU-MIMO, up to 4.8 Gbps (BW160)
Spatial Streams6 total
Coverage Area140 m² (1,500 ft²)
Max. Client Count300+
Ethernet Ports1 × 1 GbE RJ45
Uplink1 GbE
PoE In802.3af/at (44–57V DC)
PoE OutNot specified by vendor
Max. Power Consumption13 W
Power MethodPoE (adapter included)
Antenna Gain2.4 GHz: 3 dBi 5 GHz: 5 dBi
Max. TX Power2.4 GHz: 22 dBm 5 GHz: 26 dBm
Max. BSSIDs8 per radio
Supported Data RatesWi-Fi 6 (HE): 7.3 Mbps – 4.8 Gbps Wi-Fi 5 (VHT): 6.5 Mbps – 3.4 Gbps Wi-Fi 4 (HT): 6.5 Mbps – 600 Mbps
Channel Bandwidth20/40/80/160 MHz (HE, VHT, HT)
Operating Frequency2.4 GHz: 2400–2472 MHz (US/CA), 2400–2483.5 MHz (WW) 5 GHz: U-NII-1/2/2C/3 bands
FeaturesWireless Meshing, Band Steering, 802.11k/v/r, Advanced Radio Management, Hotspot 2.0, Captive Portal (custom branding, vouchers, payment), PPSK, Guest Network Isolation, RADIUS over TLS, Dynamic VLAN, Client Isolation, Scheduling
Environmental RatingIPX5 weatherproof (when mounted LED up)
Operating Temperature–30 to 60 °C (–22 to 140 °F)
Operating Humidity5–95% non-condensing
CoolingPassive
Enclosure MaterialPolycarbonate, aluminum
Mounting OptionsWall, pole (mounts included)
LEDsSystem (white/blue)
NDAA CompliantYes
Certifications & ApprovalsCE, FCC, IC, Anatel, SRRC
Package ContentsU6-Mesh AP, Mount accessories, PoE adapter, Quick Start Guide
WarrantyNot specified by vendor
Software RequirementsUniFi Network application v6.0.45 or later
