Description
The Ubiquiti UniFi Switch 8 60W (US-8-60W) brings powerful PoE capability and reliable gigabit switching into a sleek, silent form factor. Equipped with 8 gigabit RJ45 ports, 4 of which provide auto-sensing IEEE 802.3af PoE supply of up to 15.4 W each, this switch simplifies device connectivity and power delivery—perfect for camera, VoIP, and access point deployments. The device operates on an included 48V DC power adapter, delivering up to 60 W total PoE budget.
With a robust 8 Gbps non-blocking throughput and 16 Gbps switching capacity, the US-8-60W ensures no dropped packets under load. It handles up to 11.9 million packets per second (Mpps) forwarding rate with ease. Its compact dimensions of 148 × 99.5 × 30.7 mm allow for versatile wall or desktop placement using included mounting hardware.
Managed via the intuitive UniFi Network Controller, administrators gain centralized control over VLANs, ACLs, IGMP Snooping, LACP link aggregation, QoS, port isolation, and more. The fanless design guarantees quiet operation, while sturdy SGCC steel housing ensures durability. Its operating range (–5 to 45 °C) and 5–95% non-condensing humidity rating make it suitable for most indoor environments.
Application
Home networks, Small offices, Retail setups, Small business PoE deployments
Key Features
-
✔ 8 × Gigabit RJ45 ports; 4 support auto-sensing IEEE 802.3af PoE (15.4 W each)
-
✔ Total PoE budget up to 60 W, powered via included 48 V DC adapter
-
✔ 8 Gbps non-blocking throughput, 16 Gbps switching capacity, 11.9 Mpps forwarding rate
-
✔ Compact and fanless design; silent operation ideal for desktop and wall-mount use
-
✔ Powerful Layer 2 feature set: VLANs, LACP, ACLs, IGMP Snooping, Port Mirroring, Storm Control, Storm Limiting
-
✔ Managed by UniFi Network Controller: centralized configuration, monitoring, and client tracking
-
✔ Rugged SGCC steel enclosure; supports –5 °C to 45 °C operating temps, 5–95% non-condensing humidity
-
✔ Security slot for device locking; versatile mounting options included
