Description
The Ubiquiti UniFi Dream Machine Special Edition (UDM-SE) redefines all-in-one network appliances for medium to large-scale deployments. Powered by a Quad-core ARM Cortex-A57 at 1.7 GHz, 4 GB DDR4 RAM, and dual storage (16 GB eMMC plus integrated 128 GB SSD), it delivers robust performance and data resilience.
This 1U rack-mountable unit consolidates multiple network functions: a high-speed security gateway with IDS/IPS (3.5 Gbps), dual WAN support (10 Gb SFP+ and 2.5 Gb RJ45), an 8-port GbE PoE switch delivering up to 180 W PoE budget (comprising both PoE+ and PoE), and an NVR bay for UniFi Protect storage. It’s a true unified solution for converged networking.
Equipped with UniFi OS, it runs UniFi Network, Protect, Access, Talk, Connect, and more, all manageable via a 1.3″ touchscreen, Ethernet, or Bluetooth setup. With support for 100+ UniFi devices and 1,000+ simultaneous clients, it’s built for scalability and reliability.
Application
Enterprises, ISPs, Large Offices, Multi-service Network Infrastructures, Security-Converged Deployments
Key Features
✔ 1 U rack-mountable UniFi gateway with built-in controller and touchscreen
✔ Dual WAN: 10 Gb SFP+ and 2.5 Gb RJ45 for flexible, high-performance uplinks
✔ 8-port Gigabit PoE switch with mix of PoE and PoE+ ports—180 W total budget
✔ Integrated 128 GB SSD plus 16 GB eMMC and Optional 3.5″ NVR bay
✔ IDS/IPS throughput up to 3.5 Gbps—secure at scale
✔ Scalable: manage 100+ UniFi devices and support 1,000+ clients
✔ Supports UniFi Network, Protect, Access, Talk, Connect, and AI Apps
✔ Dual power options: internal 240 W PSU and optional DC backup (USP-RPS)
✔ Robust: metal chassis, touchscreen UI, and unified Bluetooth setup
✔ NDAA-compliant with CE/FCC/IC certifications
