Ubiquiti U-PoE+ — 30 W Gigabit PoE+ Adapter for UniFi Devices

The Ubiquiti U-PoE+ is a high-performance 30 W Gigabit PoE+ adapter designed to power UniFi access points, cameras, and VoIP devices. Delivering 48 V DC at 0.65 A, it supports full Gigabit throughput while protecting connected devices with built-in surge, clamping, and overcurrent protection. Compact and reliable, the U-PoE+ is perfect for deployments where a PoE+ switch is unavailable. With a grounded AC cable and NDAA compliance, it’s an efficient and safe solution for powering UniFi equipment.

  • Data Sheet
  • User Manual
Request a Quote
11 people are viewing this product

Description

The Ubiquiti U-PoE+ (30 W PoE+ Adapter) provides a simple, reliable way to power UniFi devices when a PoE+ switch is not available. Supporting the 802.3at PoE+ standard, the adapter delivers 48 V DC at 0.65 A (30 W) over a single Gigabit Ethernet port, ensuring stable power and high-speed data transfer.

Engineered with built-in surge protection, clamping protection, and overcurrent safeguards, the U-PoE+ enhances the safety of your network hardware. Its grounded AC power input further improves stability for professional installations.

The compact, lightweight design (100 g) and fanless operation make it suitable for desktop or wall-mounted use in home, office, and enterprise environments. Fully NDAA compliant and globally certified (CE, FCC, IC, UL, CCC), the U-PoE+ is trusted for powering UniFi access points, IP cameras, and other 802.3at-compliant devices.

Whether expanding an enterprise network or deploying standalone UniFi devices, the U-PoE+ delivers the convenience of PoE+ power with Gigabit performance and proven Ubiquiti reliability.

Application

UniFi device power supply, Enterprise networks, Small offices, Home Wi-Fi deployments, CCTV setups

Key Features

✔️ 30 W Gigabit PoE+ adapter (802.3at standard)
✔️ 48 V DC, 0.65 A output for high-power devices
✔️ Built-in surge, clamping, and overcurrent protection
✔️ Grounded AC input for enhanced safety
✔️ Fanless, compact, and lightweight design (100 g)
✔️ Full Gigabit throughput for data + power delivery
✔️ NDAA compliant and globally certified
✔️ Ideal for UniFi APs, cameras, and VoIP phones

Specifications

Specification Details
Brand Ubiquiti
Model / Product Code U-PoE+ (PoE+ Adapter 30 W)
Ethernet Port 1 × Gigabit RJ45 (PoE output + data)
Output Voltage / Current 48 V DC, 0.65 A
Max Power Output 30 W
PoE Standard 802.3at (PoE+)
AC Input Voltage 100–240 V AC @ 50/60 Hz
Power Connector IEC-320 C6
Efficiency 84.25%+
Surge Protection Difference and common mode
Clamping Protection 11 V Data, 60 V Power
Max Surge Discharge 1500 A (8/20 μs) Power
Peak Pulse Current 36 A (10/1000 μs) Data
Response Time < 1 ns
Shunt Capacitance < 5 pF Data
Dimensions 86 × 46 × 33 mm (3.4 × 1.8 × 1.3″)
Weight 100 g (3.5 oz)
Operating Temperature 0 to 40 °C (32 to 104 °F)
Storage Temperature –30 to 70 °C (–22 to 158 °F)
Operating Humidity 10% to 90% noncondensing
Certifications & Approvals CE, FCC, IC, UL, CCC; NDAA compliant
Warranty Limited manufacturer warranty (as per Ubiquiti policy)
Package Contents U-PoE+ adapter, AC cable
