Description
The Sopto Duplex LC/UPC to LC/UPC OM2 Patch Cord – 2.0mm LSZH is a high-quality multimode fiber optic cable optimized for short-distance 10 Gbps transmission in LANs, data centers, and telecom environments. Built with OM2 (50/125 µm) graded-index multimode fiber, it provides low attenuation and excellent signal integrity across high-bandwidth applications.
Equipped with LC/UPC connectors on both ends, this duplex design supports simultaneous bidirectional communication and ensures stable performance with insertion loss ≤ 0.3 dB and return loss ≥ 35 dB. The 2.0 mm LSZH (Low Smoke Zero Halogen) jacket offers flame resistance and low toxicity, making it suitable for indoor and enclosed environments.
Compliant with IEC 61754, ISO/IEC 11801, and RoHS, this Sopto patch cord ensures dependable multimode connectivity for network switches, servers, ODF panels, and storage systems requiring OM2 optical links.
Application
Data centers, Enterprise LAN, Server interconnections, Telecom systems, Optical distribution frames (ODF), Storage area networks (SAN)
Key Features
✅ LC/UPC to LC/UPC duplex multimode patch cord
✅ OM2 50/125 µm fiber supports 10 Gbps transmission
✅ 2.0 mm LSZH jacket — flame-retardant and low-smoke
✅ Low insertion loss (≤ 0.3 dB) and high reliability
✅ Precision-polished LC connectors for minimal back reflection
✅ Fully compliant with IEC 61754, ISO/IEC 11801, RoHS
✅ Ideal for indoor, rack, and data center cabling
✅ Available in multiple lengths (1 m – 50 m)
