Description

The RG-EST350 V2 is part of Reyee’s EST series of outdoor wireless bridges, engineered for robust point-to-point (PTP) or point-to-multipoint (PTMP) utilization in CCTV, campus, or remote backhaul networks. Operating on 5 GHz with 802.11ac dual-stream (2×2 MIMO), it delivers up to 867 Mbps wireless link speed under ideal conditions.

One of the standout features is factory pairing—units are pre-configured as a pair to minimize field alignment complexity. Despite that, site tuning is still recommended for best performance. It can reliably cover distances up to 5 km, with capacity to support 45 camera streams at 3 km and 20 camera streams at 5 km under H.265 / 2 MP at 3 Mbps settings.

Weather resilience is strong: the unit is rated IP54, and built to operate between –30 °C and 65 °C. It also has surge / lightning protection integrated to safeguard the radio link infrastructure.

For management, the RG-EST350 V2 supports remote monitoring and statistics via Ruijie Cloud (signal metrics, link quality, utilization).

This bridge is ideal for surveillance system backhaul, connecting remote camera clusters, campus link expansion, and bridging network gaps where fiber is impractical.

Application

Surveillance (CCTV) backhaul, Point-to-Point / Campus links up to 5 km, Remote camera aggregation, Building-to-building connectivity, Rural connectivity extensions

Key Features

✔️ 5 GHz dual-stream (2×2 MIMO) with 802.11ac support
✔️ Up to 867 Mbps wireless link speed
✔️ Long-range up to 5 km in line-of-sight conditions
✔️ Factory-paired for plug-and-play deployment
✔️ IP54 weatherproof, –30 °C to 65 °C rated
✔️ Integrated 4 kV lightning / surge protection
✔️ Supports high-density camera backhaul (45 @ 3 km, 20 @ 5 km)
✔️ Ruijie Cloud remote monitoring and link statistics
✔️ 2 × Gigabit Ethernet ports for uplink / redundancy
