Ruijie Reyee RG-ES205GC — 5-Port Gigabit Managed Switch

he Ruijie Reyee RG-ES205GC is a smart cloud-managed Gigabit switch designed for CCTV, small offices, and home networks. It provides 5 Gigabit Ethernet ports with 10 Gbps switching capacity, delivering fast and reliable wired connectivity for IP cameras, access points, and business devices. With cloud management support, administrators can monitor and configure networks remotely with ease. Featuring a compact fanless design, this switch offers silent operation and long-term durability, making it a smart and dependable choice.

10 people are viewing this product

Description

The Ruijie Reyee RG-ES205GC is a 5-port Gigabit smart cloud-managed non-PoE switch that delivers stable, high-performance connectivity for small businesses, surveillance networks, and home offices. It belongs to the Reyee ES200 series, known for combining professional-grade networking features with simplicity and cost-effectiveness.

Equipped with 5 Gigabit Ethernet ports, the RG-ES205GC ensures smooth data transfer for IP cameras, access points, computers, and core network devices. Its switching capacity of 10 Gbps guarantees reliable performance in busy environments. Cloud-based management via the Ruijie Cloud platform allows IT administrators or service providers to configure, monitor, and troubleshoot remotely through mobile or web interface, simplifying deployment and maintenance.

Built with a fanless design, the switch operates silently and is suitable for noise-sensitive settings such as offices, schools, or retail shops. It also supports VLAN segmentation, MAC address learning, and broadcast storm control for enhanced network security and efficiency. Compact, energy-efficient, and easy to deploy, the RG-ES205GC is an ideal choice for SMBs, CCTV setups, and WISP providers who need a reliable and affordable Gigabit switch.


Application

Small offices, Enterprise networks, ISPs, CCTV deployments, Home Wi-Fi, Barangay surveillance networks, Local ISPs/WISPs, Internet cafés, Schools and LGUs, Rural CCTV installations


Key Features

✔️ 5 × Gigabit Ethernet ports for reliable high-speed connections
✔️ 10 Gbps switching capacity for stable performance
✔️ Supports VLAN segmentation and broadcast storm control
✔️ Smart cloud management via Ruijie Cloud platform
✔️ Silent fanless design suitable for offices and retail spaces
✔️ Compact and lightweight build for flexible deployment
✔️ Ideal for CCTV networks, small businesses, and WISPs
✔️ Backed by CE certification for quality compliance

Specifications

Specification Details
Ports 5 × 10/100/1000Base-T (Gigabit)
Layer Type Layer 2
Switching Capacity 10 Gbps
Forwarding Rate 7.44 Mpps
MAC Address Table 2,000 entries
Maximum VLANs 16
Cooling Fanless
Port Surge Protection 4 kV
Dimensions (W × D × H) 119 × 75 × 24 mm
Weight (with package) 0.36 kg
MTBF >200,000 hours
Warranty 3 Years
Certification CE
