Description

The Reyee RG-RAP6202(G) Outdoor Access Point delivers high-speed dual-band connectivity in harsh outdoor conditions. Supporting Wi-Fi 5 (802.11ac Wave 2) with speeds up to 1,267 Mbps (400 Mbps at 2.4 GHz + 867 Mbps at 5 GHz), it uses 2×2 MU-MIMO to serve multiple users simultaneously, reducing congestion and enhancing performance.

Designed for outdoor deployments, the unit features IP68 waterproof and dustproof housing, a flame-retardant and wind-resistant casing, and 4 kV lightning protection. It operates reliably in temperatures from –30 °C to +65 °C, making it suitable for diverse climates.

Equipped with four built-in omni-directional high-gain antennas, the RG-RAP6202(G) provides wide coverage—up to 100 m at 2.4 GHz and 300 m at 5 GHz in open environments. It supports two Gigabit Ethernet ports, flexible power options via 802.3af/at PoE or 12 V DC, and has a low power consumption of ≤13 W.

The device supports Reyee Mesh networking for controller-free expansion and can be managed through the Ruijie Cloud / Reyee Cloud platform for centralized, remote control. With capacity for around 110 clients, it is ideal for campuses, plazas, resorts, parking areas, and public Wi-Fi zones. Backed by a 3-year warranty, it combines performance, ruggedness, and scalability.

Application

Outdoor hotspots, Campus networks, Resorts, Parks, Plazas, Parking lots, Public Wi-Fi zones

Key Features

✔️ Wi-Fi 5 (802.11ac Wave 2) with up to 1,267 Mbps throughput
✔️ Omni-directional coverage with 4 integrated high-gain antennas
✔️ IP68-rated enclosure for dust, rain, and harsh weather
✔️ 2 × Gigabit Ethernet ports (10/100/1000 Base-T)
✔️ Supports PoE (802.3af/at) and 12 V DC power input
✔️ Wide coverage range: up to 100 m (2.4 GHz) and 300 m (5 GHz)
✔️ Built for harsh environments: –30 °C to +65 °C, 4 kV lightning protection
✔️ Cloud management and Reyee Mesh for easy expansion
✔️ Backed by 3-year warranty
