Description
The Reyee RG-NBS3200-48GT4XS is an advanced Layer 2+ Gigabit managed switch designed for high-performance enterprise and campus networks. It combines 48 Gigabit Ethernet ports with 4 fixed 10G SFP+ uplink interfaces, offering flexible connectivity for both access and aggregation layers.
Delivering up to 176 Gbps switching capacity and a high 130 Mpps forwarding rate, the RG-NBS3200-48GT4XS provides reliable, low-latency performance ideal for bandwidth-intensive applications. The switch supports a wide range of Layer 2+ features, including VLAN segmentation, link aggregation (LACP), STP/RSTP/MSTP, IGMP snooping, QoS prioritization, and ACL security policies, ensuring optimal traffic management and network protection.
With Ruijie / Reyee Cloud management, IT administrators can deploy, configure, and monitor the switch remotely through a simple web interface or mobile app, enabling zero-touch provisioning and centralized control.
Engineered for reliability, it includes 6 kV surge protection, a 16K MAC address table, and 9K jumbo frame support for handling large data transfers. Its rack-mountable 1U chassis makes it easy to integrate into enterprise cabinets.
Designed for enterprise offices, hotels, schools, factories, and surveillance backbones, the RG-NBS3200-48GT4XS delivers exceptional scalability, simplified management, and long-term durability backed by a 5-year warranty.
Application
Enterprise networks, Education campuses, Hospitality IT systems, Industrial factories, Retail and surveillance infrastructures
Key Features
✔️ 48 × Gigabit RJ45 ports + 4 × 10G SFP+ uplinks
✔️ 176 Gbps switching capacity for high-throughput performance
✔️ Layer 2+ managed features: VLAN, LACP, QoS, STP/RSTP/MSTP, ACLs
✔️ Cloud-based management via Ruijie / Reyee Cloud platform
✔️ 6 kV surge protection and enterprise-grade reliability
✔️ 16K MAC address table, 9K jumbo frame support
✔️ 1U rack-mountable form factor for easy integration
✔️ Backed by a 5-year warranty
