Reyee RG-ES216GC — 16-Port Gigabit Cloud-Managed Switch

The Reyee RG-ES216GC is a 16-port Gigabit managed cloud switch with 2 Gigabit combo uplink ports, ideal for SMBs, retail, hotels, schools, and surveillance projects. It supports VLAN, QoS, STP/RSTP, IGMP snooping, and ACLs for secure, optimized traffic control. With centralized Ruijie Cloud management, fanless energy-efficient design, and a 3-year warranty, it delivers reliable enterprise-grade performance in a compact 1U form factor.

Description

The Reyee RG-ES216GC is a professional Layer 2 Gigabit switch designed for modern small-to-medium business networks. Equipped with 16 × 10/100/1000 Mbps RJ-45 ports and 2 × Gigabit combo uplinks, it provides stable wired connectivity with flexibility for fiber backhaul or uplink aggregation.

As part of Reyee’s cloud-managed portfolio, the RG-ES216GC integrates seamlessly with Ruijie Cloud, enabling IT administrators to configure, monitor, and troubleshoot remotely. Supported features include VLAN segmentation, ACL-based traffic control, QoS for prioritizing critical applications, spanning tree protocol for loop prevention, and IGMP snooping for multicast optimization.

Compact and rack-mountable, the RG-ES216GC features a fanless design for silent operation, low power consumption, and high reliability. With security enhancements such as storm control, broadcast suppression, and port security, it ensures safe, efficient performance. Backed by a 3-year warranty, it’s an excellent choice for offices, hotels, retail, education, and surveillance networks.


Application

SMB office networks, Retail shops, Hotels, Education, Surveillance networks, Branch enterprise LANs


Key Features

✔️ 16 × Gigabit Ethernet ports for high-speed LAN connectivity
✔️ 2 × Gigabit combo uplinks for flexible fiber/ethernet backhaul
✔️ Layer 2 features: VLAN, QoS, ACL, STP/RSTP, IGMP snooping
✔️ Security: storm control, port security, broadcast suppression
✔️ Cloud-managed via Ruijie Cloud and Reyee App
✔️ Fanless, energy-efficient, silent design
✔️ Compact, 1U rack-mountable form factor
✔️ Backed by a 3-year warranty

Specifications

SpecificationDetails
Ports16 × 10/100/1000 Base-T
Layer TypeLayer 2
Switching Capacity32 Gbps
Forwarding Rate23.81 Mpps
MAC Address Table8,000
Maximum VLAN16
FanFanless
Port Surge Protection6 kV
Dimensions (W × D × H)440 × 165 × 44 mm
Weight (with package)2.7 kg
MTBF> 200,000 hours
Warranty3 Years
