Description
The MikroTik RB1100AHx4 Dude Edition is engineered for enterprise networking and high-capacity management tasks. Housed in a robust 1U rackmount unit, it delivers maximum throughput of up to 7.5 Gbps, powered by an Annapurna AL21400 quad‑core 1.4 GHz CPU with IPsec acceleration for high-speed encrypted communications (up to 2.2 Gbps with AES‑128).
This edition is enhanced with abundant storage capabilities including a pre-installed 60 GB M.2 SSD, two additional M.2 slots, and two SATA3 ports—ideal for running the Dude network management server, proxy caching, or other intensive services. Featuring 13 Gigabit Ethernet ports, an RS232 serial console, and redundant power input options (dual AC, -48 V DC, or PoE-in 802.3af/at), it ensures flexible deployment and continuous uptime.
Advanced hardware monitoring tools—including voltage, current, and temperature sensors—along with IPsec hardware offloading and a passive cooling design, make it both reliable and durable for 24/7 operation in demanding environments.
Application
Enterprise routers, Network management servers (Dude), ISP backbones, Secure high-throughput routing
Key Features
✔️ Quad-core Cortex-A15 1.4 GHz (Annapurna AL21400) delivering up to 7.5 Gbps throughput
✔️ IPsec hardware acceleration up to ~2.2 Gbps with AES-128
✔️ Pre-installed 60 GB M.2 SSD with additional M.2 and SATA3 slots for storage expansion
✔️ 13 Gigabit Ethernet ports and RS232 console for maximum connectivity
✔️ Dual redundant power inlet: AC (2x), -48 V DC, or PoE-in (802.3af/at)
✔️ Extensive hardware monitoring: voltage, current, temperature sensors
✔️ RouterOS v6 with Level 6 license for full enterprise and routing features
✔️ Passive cooling design ensures silent, reliable performance
