MikroTik RB1100AHx4 — 13-Port Gigabit Enterprise Router with Quad-Core CPU & IPsec Acceleration

The MikroTik RB1100AHx4 is a powerful 1U rackmount router designed for enterprise and ISP-grade networks. Equipped with a quad-core ARM Cortex-A15 CPU, 1 GB RAM, and 13 Gigabit Ethernet ports, it ensures fast routing and switching performance. Dual redundant power supplies with failover add reliability, while IPsec hardware acceleration enhances security. Running RouterOS L6, it supports advanced routing, VPN, and firewall features. A robust, rack-ready solution for demanding network environments that require high throughput and stability.

Description

The MikroTik RB1100AHx4 is a high-performance router built for enterprise networks, data centers, and ISPs requiring speed, security, and reliability. Packaged in a slim 1U rackmount case, it integrates a quad-core Cortex-A15 CPU clocked at 1.4 GHz with hardware-based IPsec acceleration, delivering exceptional throughput for encrypted traffic.

With 13 Gigabit Ethernet ports, the RB1100AHx4 provides extensive connectivity for routing and switching tasks. It comes with 1 GB of RAM and 128 MB NAND storage, ensuring stability under heavy loads. Dual redundant power supplies with failover protection keep networks online without interruption, while active cooling maintains reliable performance.

The router runs MikroTik’s RouterOS v6 (upgradable to v7) with a Level 6 license, unlocking full enterprise features including BGP, OSPF, MPLS, advanced firewalling, bandwidth management, and VPN services.

Built for long-term operation, the RB1100AHx4 is ideal for ISPs, enterprise backbones, and organizations needing high throughput, secure routing, and 24/7 dependability.


Application

Enterprise networks, ISP backbones, Data centers, Secure routing


Key Features

✔️ Quad-core Cortex-A15 1.4 GHz CPU with IPsec hardware acceleration
✔️ 13× Gigabit Ethernet ports for extensive connectivity
✔️ Dual redundant power supplies with failover support
✔️ RouterOS L6 for advanced routing, VPN, MPLS, and firewall features
✔️ 1 GB RAM and 128 MB NAND storage for stability under heavy loads
✔️ 1U rackmount enclosure for easy integration in server racks
✔️ Designed for high-performance enterprise and ISP-grade networking
✔️ Active cooling system for reliable 24/7 operation

Specifications

SpecificationDetails
BrandMikroTik
Model / Product CodeRB1100AHx4 / RB1100x4
ArchitectureARM 32-bit
CPUAnnapurna Labs AL21400
CPU Core Count4
CPU Nominal Frequency1.4 GHz
Switch Chip ModelRTL8367
Operating SystemRouterOS (License Level 6)
Memory (RAM)1 GB
Storage128 MB NAND
Memory Card Slot1× microSD
MTBF~200,000 hours at 25 °C
Tested Ambient Temperature−40 °C to +70 °C
IPsec Hardware AccelerationYes
Dimensions443 × 148 × 44 mm
Cooling TypePassive
Number of AC Inputs2
AC Input Range100–240 V
Number of DC Inputs2 (2-pin terminal, PoE-in)
2-Pin Terminal Input Voltage−48 V, 12–57 V
PoE-in802.3af/at
PoE-in Input Voltage20–57 V
Max Power Consumption20 W
Ethernet Ports13× 10/100/1000 Mbps
Serial Console PortRS232
Other HardwareCurrent monitor, PCB temperature monitor, Voltage monitor, Mode button, Beeper
Environmental RatingIndoor use, IP20
Certifications & ApprovalsCE, EAC, RoHS
Warranty1 year (as specified by MikroTik)
Package ContentsRB1100AHx4 unit, power cables, rackmount kit
