MikroTik LHG XL 5 ax

The MikroTik LHG XL 5 ax is an extra‑large, long‑range outdoor Wi‑Fi 6 CPE housed in a rugged IP54‑rated enclosure. Featuring a powerful 27 dBi directional antenna, it’s capable of establishing point‑to‑point links up to **30 km** in ideal conditions. Powered by a dual‑core ARM IPQ‑5010 CPU (800 MHz), with 256 MB RAM, 128 MB NAND storage, and licensed for RouterOS v7 Level 3, it delivers up to 1200 Mbps in the 5 GHz band (802.11a/n/ac/ax) with WPA3 encryption and QCN‑6102 chipset support. It runs passively cooled, drawing up to 5 W via a single 12–28 V passive PoE input. Includes a Gigabit Ethernet port, CPU temperature monitoring, and operates reliably from –40 °C to 70 °C.

  • User Manual
Request a Quote
10 people are viewing this product

Description

Need a fast, stable connection across large distances? Whether you’re bridging two buildings, connecting a remote site, or sharing your internet with nearby infrastructure — the new LHG Wi-Fi 6 series is built for the challenge. And here’s the best part: it has kept the same pricing as the previous generation. High performance, long range, and Wi-Fi 6 — all without breaking the budget.

The 802.11ax standard brings crucial improvements for long-distance wireless links — including better spectral efficiency, higher modulation rates (1024-QAM), and lower latency. That means stronger performance even in noisy environments and faster, more stable connections over a greater distance. Combined with WPA3 encryption and RouterOS v7, the LHG ax series is ready for the challenges of modern outdoor networking. Order yours today — and be ready too!

LHG XL 5 ax is an extra large long-range CPE with a 27 dBi antenna. Perfect for links up to 30 km in ideal conditions. Check related devices below for the regular version if you’re working at a closer range!

Specifications

Model LHG XL 5 ax
Product code LHG-5axD-XL
Architecture ARM 64bit
CPU IPQ-5010
CPU core count 2
CPU nominal frequency 800 MHz
RouterOS license 3
Size of RAM 256 MB
Storage size 128 MB
Storage type NAND
Tested ambient temperature -40°C to 70°C
Powering
Number of DC inputs 1 (PoE-IN)
Max power consumption 5 W
Cooling type Passive
PoE in Passive PoE
PoE in input voltage 12–28 V
Wireless Specifications (5 GHz)
Max data rate 1200 Mbit/s
Number of chains 2
Standards 802.11a/n/ac/ax
Antenna gain 27 dBi
Chip model QCN-6102
Wi-Fi generation Wi-Fi 6
Ethernet
10/100/1000 Ethernet ports 1
Other
CPU temperature monitor Yes
Certification & Approvals
Certification CE, FCC, IC, EAC, ROHS
IP rating 54
