Description
The MikroTik CRS504-4XQ-OUT is a high-capacity outdoor Cloud Router Switch designed for service providers, enterprise backbones, and data center-grade connectivity. With 4× 100G QSFP28 ports, this switch provides exceptional throughput and flexibility, allowing direct 100G uplinks or break-out to multiple 25G and 10G connections depending on deployment needs.
Powered by a 4-core ARMv8 CPU running at 1.8 GHz, paired with 4 GB DDR4 RAM and 128 MB NAND storage, the CRS504 delivers reliable performance with hardware offloading for Layer 2/3 switching. RouterOS v7 ensures advanced VLANs, routing, firewall, and monitoring features, making it suitable for complex and large-scale network deployments.
The CRS504-4XQ-OUT is built for the toughest environments with an IP66-rated outdoor enclosure, passive cooling, and dual hot-swappable power supplies (18–57 V DC). Its fanless design ensures silent, low-maintenance operation, while wide temperature tolerance guarantees reliability in extreme conditions.
Whether powering ISP towers, expanding enterprise backbones, or delivering multi-gigabit rural connectivity, the CRS504-4XQ-OUT combines raw performance, flexible uplinks, and rugged durability in one solution.
Application
ISP backbone, Enterprise networks, Data centers, High-speed outdoor deployments
Key Features
-
✅ 4× 100G QSFP28 ports with breakout options for 25G/10G
-
✅ 4-core ARMv8 CPU at 1.8 GHz with 4 GB DDR4 RAM
-
✅ RouterOS v7 with hardware offloading for Layer 3 switching
-
✅ Dual hot-swappable DC power supplies (18–57 V)
-
✅ Fanless passive cooling design for silent operation
-
✅ Rugged IP66 outdoor-rated enclosure
-
✅ Wide operating temperature tolerance for harsh environments
-
✅ Future-proof high-capacity solution for ISP and enterprise backbones
