MikroTik CRS326-24G-2S+RM

The MikroTik CRS326-24G-2S+RM is a versatile 24-port Gigabit Ethernet switch with 2 SFP+ ports, offering wire-speed connectivity and advanced switching features. It features a “Dual boot” option, allowing you to choose between RouterOS and SwOS, based on your preference for routing capabilities or simplified switch functionality. Ideal for managed networks, it supports port forwarding, VLANs, traffic mirroring, bandwidth limitations, and more. The SFP+ cages support both 1.25 Gb and 10 Gb modules, making it a flexible solution for high-speed connectivity.

Description

24 Gigabit port switch with 2 x SFP+ cages in 1U rackmount case, Dual boot (RouterOS or SwitchOS)

MikroTik CRS326-24G-2S+RM is a SwOS/RouterOS powered 24 port Gigabit Ethernet switch with two SFP+ ports, wire speed connectivity and several new switching features!

It has “Dual boot” feature that allows you to choose which operating system you prefer to use, RouterOS or SwOS. If you prefer to have a simplified switch only OS with more switch specific features, use SwOS. If you are used to Winbox and would like the ability to use routing and other Layer 3 features on some ports in your CRS, boot and use RouterOS. You can select the desired operating system from RouterOS, from SwOS or from the RouterBOOT loader settings.

It gives you all the basic functionality for a managed switch, plus more: allows to manage port-to-port forwarding, apply MAC filter, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields. SFP cage supports both 1.25 Gb SFP and 10 Gb SFP+ modules.

Specifications

Product codeCRS326-24G-2S+RM
ArchitectureARM 32-bit
CPU98DX3236
CPU core count1
CPU nominal frequency800 MHz
Switch chip model98DX3236
Dimensions443 x 144 x 44 mm
RouterOS license5
Operating SystemRouterOS / SwitchOS
Size of RAM512 MB
Storage size16 MB
Storage typeFLASH
MTBFApproximately 200,000 hours at 25°C
Tested ambient temperature-40°C to 60°C
Powering
Number of DC inputs2 (PoE-IN, DC jack)
DC jack input Voltage10-30 V
Max power consumption24 W
Cooling typePassive
PoE inPassive PoE
PoE in input Voltage10-30 V
Ethernet
10/100/1000 Ethernet ports24
Fiber
SFP+ ports2
Peripherals
Serial console portRJ45
Certification & Approvals
CertificationCE, EAC, ROHS
Parts Included24V 1.2A power adapter,  Rack ears, screw sets
