Description
The Huawei eKitEngine AP673 is an advanced indoor access point incorporating the new IEEE 802.11be (Wi-Fi 7 / EHT) standard. It is designed for high-traffic indoor environments such as enterprise offices, hospitals, shopping centers, and public venues requiring multi-gigabit wireless performance.
Across its three radios it provides:
-
2.4 GHz band with 2×2 MIMO
-
5 GHz band with 2×2 MIMO
-
6 GHz band with 4×4 MIMO
The device supports up to 13.66 Gbps total data rate: ~0.69 Gbps on 2.4 GHz, ~1.44 Gbps on 5 GHz, and ~11.53 Gbps on 6 GHz.
Management options include Huawei’s eKit App, SNC platform, or internal/hosted controllers in Fit/Fat mode. It can be powered via PoE or DC adapter.
Deployment is flexible: ceiling, wall, or junction box. It supports up to 30 SSIDs and 1024 client devices.
Designed for reliability: operates between -10 °C to +50 °C, high humidity tolerance, altitude up to 5000 m.
Application
Routers / Switches / APs → Enterprise networks, SME networks, Indoor high-density spaces, Hospitals, Retail & Shopping Centres
Key Features
✔️ Tri-band Wi-Fi 7 (802.11be) with 2.4/5/6 GHz radios for max throughput ~13.66 Gbps
✔️ 4×4 MIMO on 6 GHz band; 2×2 on 2.4 GHz & 5 GHz
✔️ Built-in smart antennas for adaptive coverage and interference suppression
✔️ PoE-in support (IEEE 802.3at/af) or direct DC input
✔️ Supports up to 30 SSIDs, 1024 client devices, cloud & local management modes (Fit / Fat / cloud)
✔️ Peak transmit power: 23 dBm (2.4 / 5 GHz), 26 dBm (6 GHz) combined; antenna gains around 4-5 dBi per chain
✔️ Flexible mounting: ceiling, wall, junction box; durable operating range (-10 °C to +50 °C, high humidity)
