COMFAST CF-EW85 — 1300 Mbps Outdoor Access Point

The COMFAST CF-EW85 is a high-power outdoor dual-band wireless router and access point delivering up to 1300 Mbps combined throughput. Powered by Qualcomm chipsets and three 5 dBi antennas, it offers stable 2.4 GHz and 5 GHz coverage with Gigabit LAN/WAN ports and PoE support. Its IP66 weatherproof housing and long MTBF make it perfect for WISP, campus, and resort networks needing reliable long-range outdoor Wi-Fi.

  • Data Sheet
  • User Manual
Request a Quote
7 people are viewing this product

Description

The COMFAST CF-EW85 is a professional dual-band (2.4 GHz + 5 GHz) outdoor access point and router engineered for extended Wi-Fi coverage and stable high-speed connectivity. Using Qualcomm’s QCA9563 + QCA9886 + QCA8337 chipset trio, it delivers exceptional wireless performance up to 1300 Mbps (450 Mbps @ 2.4 GHz + 867 Mbps @ 5 GHz).

Equipped with 3 × 5 dBi external antennas and a high output power of 29 dBm (800 mW), the CF-EW85 ensures reliable signal strength across wide outdoor environments. It supports multiple operation modes (AP, Router, Repeater, WISP) to fit diverse deployment needs.

The unit features three Gigabit ports (1 × WAN + 2 × LAN), PoE input (24 V 1 A), and low power consumption under 18 W. Designed for wall or pole installation, its IP66-rated weatherproof enclosure provides resistance against dust, moisture, and extreme temperatures (–10 °C ~ 55 °C). With an MTBF exceeding 250,000 hours, the CF-EW85 guarantees long-term stability for outdoor network infrastructures.

Ideal for resorts, campuses, enterprises, and rural WISP projects, this model combines professional reliability, dual-band efficiency, and flexible PoE deployment—all in one durable outdoor platform.

Application

Outdoor Wi-Fi coverage, WISP deployments, Campus and resort networks, Long-range dual-band access, Point-to-multipoint links

Key Features

✔️ Dual-band 2.4 GHz + 5 GHz with up to 1300 Mbps throughput
✔️ Qualcomm triple-chipset architecture for stable, long-range links
✔️ 3 × 5 dBi external antennas with 29 dBm (800 mW) output power
✔️ IP66 weatherproof enclosure for harsh outdoor environments
✔️ PoE-powered (24 V 1 A) for flexible remote installation
✔️ 3 Gigabit ports (1 WAN + 2 LAN) for high-speed networking
✔️ < 18 W power consumption with > 250,000 h MTBF
✔️ Ideal for outdoor Wi-Fi expansion, WISP, and enterprise coverage

Specifications

Specification Details
Brand COMFAST
Model / Product Code CF-EW85
CPU / Chipset QCA9563 + QCA9886 + QCA8337
PA Modules 2.4 G PA: SKY65900 × 3; 5.8 G PA: SKY85743-21 × 2
Memory 128 MB DDR2
Storage (Flash) 16 MB
Wi-Fi Standard IEEE 802.11 a/b/g/n/ac
Wireless Frequency 2.4 GHz (802.11 b/g/n); 5.8 GHz (802.11 a/n/ac)
Max Data Rate 2.4 GHz – 450 Mbps; 5.8 GHz – 867 Mbps
Antenna 3 × 5 dBi external antennas
Output Power (Max) 29 dBm (800 mW)
Receive Sensitivity (Min) –96 dBm
Ethernet Ports 1 × 10/100/1000 Mbps RJ45 WAN; 2 × 10/100/1000 Mbps RJ45 LAN; 1 × RESET; 1 × DC
Power Supply 24 V 1 A PoE power supply
Power Consumption < 18 W
Waterproof Rating IP66
MTBF > 250,000 hours
Installation Wall or pole mount
Dimensions (Body) 90 mm × 388 mm (without antennas)
Antenna Length 188 mm
Total Height 576 mm (with antennas)
Operating Temperature –10 °C ~ +55 °C
Storage Temperature –40 °C ~ +70 °C
Operating Humidity 10 % – 90 % RH (non-condensing)
Storage Humidity 5 % – 95 % RH (non-condensing)
Certifications & Approvals CE, FCC, RoHS
Warranty 1 Year Limited Hardware Warranty
Package Contents CF-EW85 unit, PoE Injector, Mount Kit, Manual
